Enables LED logic control for applicable devices.Creates audio routes and mute control routes.When you select Optimize in a room, Designer does the following: Optimize also creates mute control routes in rooms with MXA network mute buttons. Resets the device settings back to the factory default.ĭesigner's Optimize workflow speeds up the process of connecting systems with at least 1 microphone and 1 audio processor.
Network Audio LED Behavior LED StatusĮrror has occurred. Note: Error details are available in the event log in Shure Designer software. Network Audio: Dante audio present on the network Note: Use a PoE injector if your network switch does not supply PoE. Note: See front panel labels for block connector assignments.Ĭonnects to a computer to send and receive any combination of input and output audio channels.
#Shure qlxd4 audio overload element good software#
Set the output level in Shure Designer software to match the input sensitivity of the analog device. Provides an optional connection for microphone shield wire to chassis ground.īalanced audio output connects to an analog device. Problem detected with connected USB audio device Note: The input and output LEDs stay off when metering is set to Post-gain. Adjust output levels in Shure Designer software to avoid clipping. Tri-color LEDs indicate the audio signal level for the analog channels and connectivity status for the USB channel.
